    Clamp ceramic check valve

    Product model: H72TC
    Nominal pressure: 1.0MPa-1.6MPa
    Nominal diameter: DN50-DN600mm
    Applicable temperature: -40℃~ +425℃
    Connection type: clamp
    Main material: carbon steel, stainless steel, etc
    Suitable medium: water
    Implementation standard: National standard
    Flow direction: one-way
    Operating temperature: normal temperature
    Contact us
    • Product Details
    • Service details
    • Ordering process
    Product overview
    Pinch check valve is also called check valve or check valve, its role is to prevent the backflow of media in the pipeline. The bottom valve of the water pump suction close also belongs to the class of check valve. The opening and closing parts are automatically opened or closed by the flow and force of the medium to prevent the backflow of the medium. The check valve belongs to the automatic valve class, which is mainly used on the pipeline with one-way flow of the medium, and only allows the medium to flow in one direction to prevent accidents. According to the structure of the check valve, it can be divided into three kinds: lift check valve, swing check valve and butterfly check valve. Lift check valves can be divided into vertical and horizontal two types. Swing check valves are divided into single disc type, double disc type and multi-disc type. The butterfly check valve is straight-through, and the above check valves can be divided into three kinds of threaded connection, flange connection and welding in the connection form. Products are widely used in petroleum, chemical, pharmaceutical, power industry and other working conditions of the pipeline.

    Structural characteristics
    1, the valve and seat are made of high-performance structural toughening ceramics.
    2. The product is a hand-line ram structure. Reliable sealing, light opening and closing, easy maintenance.
    3, this product has high wear resistance, erosion resistance and other characteristics.
    4, suitable for water pipeline installation. Solenoid valve
